What are the classifications of LED strip lights?
According to the requirements of waterproof level, it is divided into: non-waterproof LED light bar. Dispensing waterproof LED flexible light bar (waterproof grade IP55). Semi-sleeve waterproof LED flexible light bar (waterproof grade IP65). Full sleeve waterproof LED flexible light bar (waterproof grade IP68). The full set of tubes is divided into a simple full set of tubes with LED strips for waterproofing, and silica gel filled with LED strips for waterproofing. The waterproof effect of glue filling is obviously better than that of a simple full-tube waterproof light bar.
According to the glue material used for waterproofing, it is divided into epoxy resin glue and silica gel. In terms of appearance and luminous effects. The light intensity of the waterproof light bar filled with silica gel is greater. And it feels comfortable and takes into account the concept of environmental protection. But he has a shortcoming, poor flexibility and fragility. In comparison, most of them still choose epoxy resin. It has good flexibility and relatively cheap cost, so it is widely used.
Divided according to the total type of chip and the number of lamp beads. There are 3528 and 5050 two kinds of lamp beads commonly used in LED flexible light strips. According to the number of lamp beads per meter, it is divided into common specifications such as 30 lamps, 48 lamps, and 60 lamps. Among them, 3528 can achieve a maximum of 120 lights/m due to its low power (single 0.06W).
Divided according to the width of the flexible light strip circuit board. The width of the LED circuit board is 5MM, 8MM, 10MM 12MM 15MM.
